| Place of Origin: | china |
| Brand Name: | ZC |
| Certification: | CE/ISO |
| Model Number: | ZC-QG |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | Negotiation |
| Packaging Details: | wood |
| Delivery Time: | on condition |
| Payment Terms: | TT or LC |
SPECIFICATION:
Size 89*41mm
Thickness 0.75-1.2mm(G300-G550Galvanzied coils and Aluzinc )
Feeding width 182mm
Standard Producing speed 300-700m/h
Max producing speed 1500m/h
Main motor 7.5kw
Power supplier 380V 50Hz 3phases according to your request
Hydraulic station 5.5kw
Hydraulic tank capacity:100L
Hydraulic cooling : Fan cooling
Hydraulic pressure: computer set
Frame and punching dies: Screw hole, chamfer, slot hole, flange cut, pipe hole, suspension, cutting
Tolerance: +- 0.5mm
Inkjet printer: EC-JET
Machine size: 4900*1000*1500mm
Weight: 5000kg
Color: according to your request
De-colier: bearing 2 tonne, automatical decoiler
| No. | Name | Quantity |
| 1 | Decoiler | 1 set |
| 2 | Hydrualic cutting device | 1 set |
| 3 | Roll forming machine system | 1 set |
| 4 | Hydraulic station | 1 set |
| 5 | Control box system | 1 set |
| 6 | Finished tables | 1 set |
